The 746XS stainless steel RTS valve with a 30° V-port design is designed for precise flow regulation in systems. Featuring a G connection and TCR for condensation return, it ensures reliable and efficient operation.
| Specification | Value |
|---|---|
| Option certificate 3.1 | Yes |
| Delta P (bar) | 10 |
| DN | DN15 - 1/2'' |
| Face to Face (mm) | 75.0 |
| Protection index (IP) | IP 67 |
| Kv (m³/h) | 5.10 |
| Body material | Stainless steel CF8M (1.4408) |
| Number of ways | 2 |
| PS (bar) | 63 |
| Connections | BSP FF |
| Anti-condensation heater | Standard |
| Positive safety | No |
| Function | Regulation |
| Electric actuator type | TCR-02T KT32 |
| Electric actuator series | TCR Series |
| Operating time (s) | 15.0 |
| Voltage | 95-265 V AC/DC |
| TS max (°C) | 180 |
| TS min (°C) | -40 |
| Warranty period | 1 year |
| CE | Risk category III |
If you have any questions about this product, please feel free to contact us.
| Product Name | Product Number | EVAC Number | Price | Add to Cart |
|---|---|---|---|---|
| BSP FF Stainless steel CF8M (1.4408) DN15 - 1/2'' 5.10 | 272642024190V3 | S1009880 |
€565.79
(excl. btw)
|
add to cart |
| BSP FF Stainless steel CF8M (1.4408) DN15 - 1/2'' 10.10 | 272642024190V6 | S1009881 |
€564.03
(excl. btw)
|
add to cart |
| BSP FF Stainless steel CF8M (1.4408) DN20 - 3/4'' 6.80 | 272643024190V3 | S1009882 |
€582.89
(excl. btw)
|
add to cart |
| BSP FF Stainless steel CF8M (1.4408) DN20 - 3/4'' 14.50 | 272643024190V6 | S1009883 |
€588.94
(excl. btw)
|
add to cart |
| BSP FF Stainless steel CF8M (1.4408) DN25 - 1'' 13.70 | 272644024190V3 | S1009884 |
€602.73
(excl. btw)
|
add to cart |
| BSP FF Stainless steel CF8M (1.4408) DN25 - 1'' 24.50 | 272644024190V6 | S1009885 |
€608.00
(excl. btw)
|
add to cart |
| BSP FF Stainless steel CF8M (1.4408) DN40 - 1''1/2 25.30 | 272646024390V3 | S1009886 |
€879.07
(excl. btw)
|
add to cart |
| BSP FF Stainless steel CF8M (1.4408) DN40 - 1''1/2 47.90 | 272646024390V6 | S1009887 |
€883.03
(excl. btw)
|
add to cart |
| BSP FF Stainless steel CF8M (1.4408) DN50 - 2'' 38.40 | 272647024390V3 | S1009888 |
€942.24
(excl. btw)
|
add to cart |
| BSP FF Stainless steel CF8M (1.4408) DN50 - 2'' 81.40 | 272647024390V6 | S1009889 |
€847.06
(excl. btw)
|
add to cart |
